Fully Electric Blow Molding Machine Description:
BE15D-620 fully electric blow molding machine use all-electric drive systems (servo motors) to complete the blow molding process. They are mainly used to produce hollow plastic products (such as bottles, containers, fuel tanks, etc.). Compared with traditional blow molding machines that rely on hydraulic or pneumatic systems, the core advantages of fully electric blow molding machines are high efficiency, energy saving, high precision and environmental protection.
Blow Molding Machine Technical Parameter:
| MACHINE TYPE(Fully Electric) | BE15D-620 |
|---|---|
| Clamping force | 150KN |
| Carriage stroke | 620mm |
| Die head | DH60-4F/4L-CD120 |
| Article | 1L |
| Net Weight | 110g |
| Cycle Time | 30s |
| Production Capability | 960 pcs/hour |
| MOULD DIMENSIONS | |
|---|---|
| Max mould width | 610mm |
| Max mould height | 450mm |
| Mould thickness | 140mm+140mm |
| Max mould weight | 400kg |
| EXTRUDER | |
|---|---|
| Outer layer | E60 |
| Regrind layer | E80 |
| Tie layer | E30 |
| Barrier layer | E30 |
| View stripe | E25 |
